Acoustic Energy AE107

The latest adaptation of Acoustic Energy’s globally acclaimed 100 Series features an all-new, innovative design from the ground up…

The 100 Series introduces a plethora of evolutionary improvements focused on refining the listening experience. All models feature our WDT (Wide Dispersion Tweeter) waveguide for improved dispersion, now taking cues from our 500 Series with mid/bass drivers moved closer to the tweeter. The drive units are all-new and designed in tandem to offer seamless integration along with improved response and power handling. Slot ports to the rear of each cabinet reduce chuffing & distortion, thanks to a new tooled vent to further smooth airflow. Finally, as a first at this price point, the 100 Series uses HDF (High Density Fibreboard) construction to allow thinner cabinet walls with no loss in mass or stiffness – the result is larger internal volume providing deeper bass response for minimal external size increase.

This elegant, compact yet powerful range of speakers embodies all the qualities Acoustic Energy is renowned for, while taking advantage of everything we’ve learned in our continuous journey of development.

The AE100² is a compact stand-mount/bookshelf loudspeaker exhibiting qualities perfectly embodying those of Acoustic Energy.

The AE100² has been designed with a view to achieving high sound pressure levels from a small enclosure. This is obtained principally through the use of a 125mm mid-bass drive unit built around an ultra-high force, long throw motor system. Bass performance is augmented by a slot shaped duct allowing for a considerable cross-sectional area while negating the issues of air turbulence.

A 25mm soft dome tweeter featuring our Wide Dispersion Technology completes the driver compliment and is housed within a 15mm HDF cabinet. Taking design cues from the award-winning 500 Series and finished in a choice of black, satin white or walnut vinyl veneer finishes. The AE100² is sure to look good placed on speaker stands or bookshelves, while delivering a sound that belies its compact size.

The AE109² is designed to offer effortless, room filling performance from a slim-line floor-standing loudspeaker in much the same way the world acclaimed original AE109 did 20 years ago. To do this, two 125mm paper drivers utilising an ultra-high force motor system are used in partnership with a 25mm soft dome tweeter. The 2.5-way crossover features a unique topology allowing integration and power handling previously un-achievable from this type of speaker. Particular attention has been paid to the phase and time alignment for the most cohesive performance possible.

Like the AE100² stand-mount speaker, the driver and crossover are housed within a substantial 15mm HDF cabinet that takes styling cues from the award winning 500 Series. The result is an audio product with clean and uncluttered lines that can still deliver the thrilling and powerful presentation Acoustic Energy owners have come to expect. Black and walnut vinyl veneer finishes are available.

As the flagship of the range, the AE120² is the largest model in the 100 series and a true 3-way design. This speaker offers a big sound from a slim-line enclosure, tastefully styled to blend into a wide range of domestic environments. Twin bass drive units underpin the room filling performance with a dedicated mid-range driver housed in its own enclosure, carefully designed to mitigate the harmful effects of rear wave reflections. Integrated within the perfectly matched Wide Dispersion Technology (WDT) waveguide, Acoustic Energy’s 25mm soft dome tweeter manages the high frequencies with controlled dispersion, high sensitivity and low distortion.

The 3-way crossover is impedance compensated to avoid the resonance issues which would otherwise slow bass delivery and colour mid-range performance. Particular attention has also been paid to the phase and time alignment for optimum integration and soundstage. The result is a loudspeaker offering smooth, wide dispersion high frequencies with a clean mid-range and lightning fast bass response. The inert cabinet enclosure is constructed from 15mm HDF and like it’s smaller AE109² brother, supplied mass loaded to help dampen cabinet vibrations. The internal bracing system has been carefully tuned to reduce cabinet resonances and mid-range colouration, whilst the new AE120² benefits from a subtlety styled, discrete black plinth to aide stability, further improving dynamics and stereo focus.

The AE105 is the latest addition to the all-new 100 Series. A versatile, 2-way loudspeaker primarily designed for wall mounting, the AE105 is equally suited to a bookcase or shelf position.

The AE105 utilises a soft dome tweeter with WDT wave guide along with two 125mm paper cone drivers, one acting as a passive radiator for improved bass performance. Optimised for vertical wall mounting with the listening position at or below the tweeter axis, the AE105 can be used to simply enhance the stereo sound from your TV, or as Front L/R, Centre and Surround channel speakers within multi-channel home cinema systems… whilst partnered with the matching AE108² compact sub-woofer.

Finished in a choice of black, white or walnut vinyl veneers, they are supplied with rear mounting plates, template, wall spacers, black and light grey grilles for easy integration within any room décor.

The AE100² is a compact stand-mount/bookshelf loudspeaker exhibiting qualities perfectly embodying those of Acoustic Energy.

The AE100² has been designed with a view to achieving high sound pressure levels from a small enclosure. This is obtained principally through the use of a 125mm mid-bass drive unit built around an ultra-high force, long throw motor system. Bass performance is augmented by a slot shaped duct allowing for a considerable cross-sectional area while negating the issues of air turbulence.

A 25mm soft dome tweeter featuring our Wide Dispersion Technology completes the driver compliment and is housed within a 15mm HDF cabinet. Taking design cues from the award-winning 500 Series and finished in a choice of black, satin white or walnut vinyl veneer finishes. The AE100² is sure to look good placed on speaker stands or bookshelves, while delivering a sound that belies its compact size.

The AE109² is designed to offer effortless, room filling performance from a slim-line floor-standing loudspeaker in much the same way the world acclaimed original AE109 did 20 years ago. To do this, two 125mm paper drivers utilising an ultra-high force motor system are used in partnership with a 25mm soft dome tweeter. The 2.5-way crossover features a unique topology allowing integration and power handling previously un-achievable from this type of speaker. Particular attention has been paid to the phase and time alignment for the most cohesive performance possible.

Like the AE100² stand-mount speaker, the driver and crossover are housed within a substantial 15mm HDF cabinet that takes styling cues from the award winning 500 Series. The result is an audio product with clean and uncluttered lines that can still deliver the thrilling and powerful presentation Acoustic Energy owners have come to expect. Black and walnut vinyl veneer finishes are available.

As the flagship of the range, the AE120² is the largest model in the 100 series and a true 3-way design. This speaker offers a big sound from a slim-line enclosure, tastefully styled to blend into a wide range of domestic environments. Twin bass drive units underpin the room filling performance with a dedicated mid-range driver housed in its own enclosure, carefully designed to mitigate the harmful effects of rear wave reflections. Integrated within the perfectly matched Wide Dispersion Technology (WDT) waveguide, Acoustic Energy’s 25mm soft dome tweeter manages the high frequencies with controlled dispersion, high sensitivity and low distortion.

The 3-way crossover is impedance compensated to avoid the resonance issues which would otherwise slow bass delivery and colour mid-range performance. Particular attention has also been paid to the phase and time alignment for optimum integration and soundstage. The result is a loudspeaker offering smooth, wide dispersion high frequencies with a clean mid-range and lightning fast bass response. The inert cabinet enclosure is constructed from 15mm HDF and like it’s smaller AE109² brother, supplied mass loaded to help dampen cabinet vibrations. The internal bracing system has been carefully tuned to reduce cabinet resonances and mid-range colouration, whilst the new AE120² benefits from a subtlety styled, discrete satin black plinth to aide stability, further improving dynamics and stereo focus.

For home cinema and multi-channel music systems, the AE107² is a 2-way horizontal mount loudspeaker designed for centre channel applications. The AE107² delivers exceptional articulation and detail throughout the vocal range, augmented by powerful bass performance from the reflex loaded rear slot port. The compact centre speaker can be sited within a cabinet or on a shelf.

The AE105 is the latest addition to the all-new 100 Series. A versatile, 2-way loudspeaker primarily designed for wall mounting, the AE105 is equally suited to a bookcase or shelf position.

The AE105 utilises a soft dome tweeter with WDT wave guide along with two 125mm paper cone drivers, one acting as a passive radiator for improved bass performance. Optimised for vertical wall mounting with the listening position at or below the tweeter axis, the AE105 can be used to simply enhance the stereo sound from your TV, or as Front L/R, Centre and Surround channel speakers within multi-channel home cinema systems… whilst partnered with the matching AE108² compact sub-woofer.

Finished in a choice of black, white or walnut vinyl veneers, they are supplied with rear mounting plates, template, wall spacers, black and light grey grilles for easy integration within any room décor.

TWEETER

Acoustic Energy’s bespoke 25mm soft dome tweeter was designed in tandem with the 100 Series bass driver to offer optimum integration and tonal matching. Paired with our Wide Dispersion Technology waveguide, the crossover region between drive units is audibly seamless whilst the high-power neodymium motor assembly ensures reliable, distortion-free high-volume playback.

DRIVERS

The 125mm bass/mid driver used in the 100 Series has been developed with a high power, long excursion motor to provide satisfying volume levels and bass extension from relatively compact enclosures. The doped paper cone enables a higher crossover point for smoother mid-range and seamless crossover with the tweeter, creating extremely high fidelity, detailed and above all musical sound reproduction.

CABINET

The 100 Series uses thin, 15mm high density (HDF) enclosures with carefully tuned bracing, reducing harmful resonances whilst retaining body and substance from compact, practical cabinets. The rear slot porting* enhances smooth bass extension with minimal room impact, allowing easy placement. The AE109² and AE120² feature inert mass-loading for additional stability and acoustic damping, all models come supplied with slim magnetic grilles.

AE100²

Drive Unit: 125mm paper cone
Tweeter: 25mm fabric dome
Frequency Range: 51Hz – 26kHz
Sensitivity: 87dB
Peak SPL: 112dB
Power Handling: 120w
Crossover Frequency: 2.9kHz
Impedance: 6ohms
Design: 2 way
Grilles: Slim, cloth magnetic fit
Dimensions (mm): 290 x 165 x 250 (HxWxD)Weight: 9.2kg (pair)
Finishes: Black, Satin White and Walnut vinyl veneer

AE109²

Drive Unit: 125mm paper cones
Tweeter: 25mm fabric dome
Frequency Range: 41Hz – 26kHz
Sensitivity: 89dB
Peak SPL: 115dB
Power Handling: 175w
Crossover Frequency: 275Hz, 2.5kHz
Impedance: 6ohms
Design: 2.5 way
Grilles: Slim, cloth magnetic fit
Dimensions (mm): 860 x 165 x 250 (HxWxD)
Spike Thread Size: M8
Weight: 16kg (each)
Finishes: Black and Walnut vinyl veneer

AE120²

Drive Unit: 125mm paper cones
Tweeter: 25mm fabric dome
Frequency Range: 39Hz – 26kHz
Sensitivity: 89dB
Peak SPL: 116dB
Power Handling: 200w
Crossover Frequency: 300Hz, 2.7kHz
Impedance: 8ohms
Design: 3 way
Grilles: Slim, cloth magnetic fit
Dimensions (mm): 950 x 165 (195*) x 295 (315*) (HxWxD)
Spike Thread Size: M8
Weight: 19kg (each)
Finishes: Black and Walnut vinyl veneer

* inc. plinth

AE105

Drive Unit: 125mm paper cones (one passive)
Tweeter: 25mm fabric dome
Frequency Range: 55Hz – 26kHz
Sensitivity: 91dB
Power Handling: 120w
Crossover Frequency: 3kHz
Impedance: 6ohms
Design: 2 way
Grilles: Slim, cloth magnetic fit (black or light grey)
Dimensions (mm): 450 x 200 x 120 (HxWxD)
Weight: 4.7kg (each)
Finishes: Black, Satin White and Walnut vinyl veneer
